| Parameter | Details |
|---|---|
| Product Name | Heavy duty pallet rack |
| Size | L2300*W1000*H2550mm (As your request) |
| Layer | 2 (As your request) |
| Load Capacity | 1000KG (As your request) |
| Upright Specification | 2550*1000*90*70*1.5mm |
| Beam Specification | 2300*100*45*1.2mm |
| Usage | Warehouse / Supermarket / Industry storage rack & shelf |
Please specify your required dimensions and load capacity per layer. We fully support customized sizes and weight capacities. The shelves can be configured with extra layers as needed (Standard setup is 2 layers).
| Model | Capacity / Layer | Size (L*W*H) mm | Layers | Standard Configuration Details |
|---|---|---|---|---|
| JS-H01 | 1000KG | 2300 * 1000 * 2550 | 2 | Upright: 2550*1000*90*70*1.5mm Beam: 2300*100*45*1.2mm |
| JS-H02 | 1500KG | 2300 * 1000 * 2550 | 2 | Upright: 2550*1000*90*70*1.5mm Beam: 2300*100*45*1.5mm |
| JS-H03 | 2000KG | 2300 * 1000 * 2550 | 2 | Upright: 2550*1000*90*70*1.8mm Beam: 2300*120*45*1.5mm |
| JS-H04 | 300KG | 2300 * 1000 * 2550 | 2 | Upright: 2550*1000*90*70*2.0mm Beam: 2300*140*45*1.5mm |
| JS-H05 | 4000KG | 2300 * 1000 * 2550 | 2 | Upright: 2550*1000*90*70*2.0mm Beam: 2300*160*45*1.5mm |
Selective pallet rack or heavy pallet rack is a common racking system in use today. Pallet rack systems consist of steel uprights and beams to support some type of decking to store goods. These systems offer maximum flexibility because the strength, height and length of the bays can be varied during installation to suit the stored material.
It is a standard industrial storage system composed of steel uprights, beams, and optional decking. It is designed to store palletized goods safely while providing direct, 100% access to every single pallet.
Yes, we support customized sizing and load capacities. You can adjust the dimensions, upright specifications, and beam styles to suit your specific loading requirements.
Our standard configurations support capacities from 1000KG to 4000KG per layer. We also support lighter requirements like 300KG configurations depending on structural specifications.
Highly flexible. The beams can be adjusted up or down to accommodate varying cargo heights. The system is also designed to be easily disassembled, reconfigured, or moved as warehouse requirements change.
Yes, these heavy duty pallet racks are fully compatible with standard forklifts, reach trucks, and other industrial material handling equipment.
A standard setup includes robust steel upright frames and horizontal load-bearing beams. The basic system comes configured with 2 layers, and additional layers can be added as needed.
