| Parameter | Details |
|---|---|
| Product Name | Heavy duty pallet rack |
| Size | L2300*W1000*H2550mm (As your request) |
| Layer | 2 (As your request) |
| Load Capacity | 1000KG (As your request) |
| Upright Specification | 2550*1000*90*70*1.5mm |
| Beam Specification | 2300*100*45*1.2mm |
| Usage | Warehouse/Supermarket/Industry storage rack & shelf |
Please tell us your required size and loading per layer. We accept customized sizes and loading capacities. If you need, the shelf can add extra layers (Standard configuration is 2 layers).
| Model | Capacity / KG | Size (L*W*H) mm | Layer | Remark |
|---|---|---|---|---|
| JS-H01 | 1000KG | 2300*1000*2550 | 2 | Upright: 2550*1000*90*70*1.5mm Beam: 2300*100*45*1.2mm |
| JS-H02 | 1500KG | 2300*1000*2550 | 2 | Upright: 2550*1000*90*70*1.5mm Beam: 2300*100*45*1.5mm |
| JS-H03 | 2000KG | 2300*1000*2550 | 2 | Upright: 2550*1000*90*70*1.8mm Beam: 2300*120*45*1.5mm |
| JS-H04 | 300KG | 2300*1000*2550 | 2 | Upright: 2550*1000*90*70*2.0mm Beam: 2300*140*45*1.5mm |
| JS-H05 | 4000KG | 2300*1000*2550 | 2 | Upright: 2550*1000*90*70*2.0mm Beam: 2300*160*45*1.5mm |
They are common, highly flexible storage systems consisting of steel uprights and beams. They support various types of decking to store goods and allow bay configurations (strength, height, and length) to be modified during installation according to the materials stored.
Yes, custom configurations are accepted. You can request specific dimensions and load-bearing capacities according to your warehousing requirements.
The standard rack comes with 2 layers. However, extra storage layers can easily be added to the racking system upon request.
Our standard models support capacities from 300KG to 4000KG per layer. These configurations can be optimized by selecting different steel upright and beam profiles.
Yes, these heavy duty pallet racks are fully compatible with standard forklifts and other industrial handling equipment, facilitating 100% quick and convenient cargo picking.
