Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System
Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System
Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System
Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System
Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System
1 / 5
Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System
Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System
Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System
Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System
Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System

Heavy Duty Cantilever Racks Heavy Duty Power Rack Warehouse Roller Rack System

Send Inquiry

Product Description

Heavy Duty Pallet Rack System Setup
Heavy Duty Pallet Racking Structure Detail
Product Specifications
Parameter Details
Product Name Heavy duty pallet rack
Size L2300*W1000*H2550mm (As your request)
Layer 2 (As your request)
Load Capacity 1000KG (As your request)
Upright Specification 2550*1000*90*70*1.5mm
Beam Specification 2300*100*45*1.2mm
Usage Warehouse/Supermarket/Industry storage rack & shelf
Customized Information
Please tell us your required size and loading capacity per layer. We accept customized dimensions and load configurations. If needed, extra layers can be added to the racking system (standard configuration is 2 layers).
Standard Model Options
Model Capacity/KG Size (L*W*H) mm Layer Remark
JS-H01 1000KG 2300*1000*2550 2 Upright: 2550*1000*90*70*1.5mm
Beam: 2300*100*45*1.2mm
JS-H02 1500KG 2300*1000*2550 2 Upright: 2550*1000*90*70*1.5mm
Beam: 2300*100*45*1.5mm
JS-H03 2000KG 2300*1000*2550 2 Upright: 2550*1000*90*70*1.8mm
Beam: 2300*120*45*1.5mm
JS-H04 3000KG 2300*1000*2550 2 Upright: 2550*1000*90*70*2.0mm
Beam: 2300*140*45*1.5mm
JS-H05 4000KG 2300*1000*2550 2 Upright: 2550*1000*90*70*2.0mm
Beam: 2300*160*45*1.5mm
Application Gallery
Racking Solution Display 1
Racking Solution Display 2
Racking Solution Display 3
Racking Solution Display 4
Racking Solution Display 5
Racking Solution Display 6
Racking Solution Display 7
Racking Solution Display 8
Racking Solution Display 9
Racking Solution Display 10
Structural Details
Pallet Rack Base and Upright structure
Pallet Rack Beam Connector
Heavy Duty Upright Frame Details
Safety Pin and Beam Joint Details
System Overview

Selective pallet rack or heavy pallet rack is a common racking system in use today. Pallet rack systems consist of steel uprights and beams to support some type of decking to store goods. These systems offer maximum flexibility because the strength, height, and length of the bays can be varied during installation to suit the stored material.

Key Strengths
  • Adapt to a wide range of goods, 100% cargo picking.
  • Compatible with forklifts and other handling equipment.
  • Beam can be flexibly adjusted to suit different cargo heights.
  • Easy to disassemble and move.
Frequently Asked Questions
Q1: What is a heavy duty pallet rack system?
A heavy duty pallet rack is a structural storage system made of steel uprights and beams designed specifically to store palletized loads. It provides high accessibility and flexibility for industrial warehouses.
Q2: Can the load capacity be customized?
Yes, our standard configurations support 1000KG to 4000KG capacity per layer, but we can customize the load capacity and dimensions based on your specific storage requirements.
Q3: How adjustable are the beams?
The beams can be easily adjusted vertically along the upright frames to accommodate different heights of pallets and cargo packages.
Q4: Are these racking systems easy to relocate?
Yes. Because of their modular design using safety pins, beams, and uprights, they are easy to disassemble, expand, or move to different sections of your warehouse.
Q5: What equipment is needed to access goods?
Our heavy-duty pallet racks are 100% accessible and fully compatible with standard forklifts, reach trucks, and other handling equipment commonly used in logistics.
