Selective pallet rack or heavy pallet rack is a common racking system in use today. Pallet rack systems consist of steel uprights and beams to support some type of decking to store goods. These systems offer maximum flexibility because the strength, height and length of the bays can be varied during installation to suit the stored material.
Product Specifications
| Product Name |
Heavy duty pallet rack |
| Size |
L2300*W1000*H2550mm (As your request) |
| Layer |
2 (As your request) |
| Load Capacity |
1000KG (As your request) |
| Upright Specification |
2550*1000*90*70*1.5mm |
| Beam Specification |
2300*100*45*1.2mm |
| Usage |
Warehouse/Supermarket/Industry storage rack & shelf |
⚙️ Customized Services
Please tell us your required size and loading capacity per layer. We accept customized sizes and load capacities. If needed, the shelf can add extra layers (Standard configuration is 2 layers).
Key Strengths
- Adapt to a wide range of goods, offering 100% cargo picking selectivity.
- Compatible with forklifts and other standard material handling equipment.
- Beams can be flexibly adjusted to suit different cargo heights.
- Easy to disassemble, reconfigure, and move.
Standard Models & Parameters
| Model |
Capacity/KG |
Size (L*W*H) mm |
Layer |
Remark |
| JS-H01 |
1000KG |
2300*1000*2550 |
2 |
Upright: 2550*1000*90*70*1.5mm
Beam: 2300*100*45*1.2mm |
| JS-H02 |
1500KG |
2300*1000*2550 |
2 |
Upright: 2550*1000*90*70*1.5mm
Beam: 2300*100*45*1.5mm |
| JS-H03 |
2000KG |
2300*1000*2550 |
2 |
Upright: 2550*1000*90*70*1.8mm
Beam: 2300*120*45*1.5mm |
| JS-H04 |
3000KG |
2300*1000*2550 |
2 |
Upright: 2550*1000*90*70*2.0mm
Beam: 2300*140*45*1.5mm |
| JS-H05 |
4000KG |
2300*1000*2550 |
2 |
Upright: 2550*1000*90*70*2.0mm
Beam: 2300*160*45*1.5mm |
Product Gallery
Structural Details
Frequently Asked Questions (FAQ)
❓ What is a heavy duty pallet rack?
A heavy duty pallet rack (or selective pallet rack) is a common industrial warehouse racking system consisting of steel uprights and beams designed to support decking for storing heavy palletized goods.
❓ Can I customize the size and load capacity?
Yes, we accept full customization for load capacity and dimensions based on your specific storage requirements. Standard sizes start from L2300*W1000*H2550mm, but they can be adjusted as requested.
❓ What is the standard number of layers for these racks?
The standard configuration is 2 layers. However, additional layers can easily be added to meet your specific space and warehouse needs.
❓ What are the main benefits of using selective pallet racks?
They offer 100% cargo picking selectivity, adapt to a wide range of goods, are fully compatible with forklifts and handling equipment, and feature adjustable beams for flexible cargo heights. They are also easy to relocate.
❓ What load capacities are available?
Our models handle standard load capacities ranging from 1000KG up to 4000KG per layer. Upright and beam specifications are adjusted accordingly to ensure safety and stability.
