| Product Name | Heavy duty pallet rack |
| Size | L2300*W1000*H2550mm ( As your request ) |
| Layer | 2 ( As your request ) |
| Load Capacity | 1000KG (As your request ) |
| Upright Specification | 2550*1000*90*70*1.5mm |
| Beam Specification | 2300*100*45*1.2mm |
| Usage | Warehouse/Supermarket/Industry storage rack & shelf |
Pls. Tell the size and loading per layer. Our accept customize size and loading capacity.
If you need, The shelf can add extra layer. (Standard is 2 layers)
| Model | Capacity/KG | Size( L*W*H )mm | Layer | Remark |
|---|---|---|---|---|
| JS-H01 | 1000KG | 2300*1000*2550 | 2 |
Upright: 2550*1000*90*70*1.5mm Beam: 2300*100*45*1.2mm |
| JS-H02 | 1500KG | 2300*1000*2550 | 2 |
Upright: 2550*1000*90*70*1.5mm Beam: 2300*100*45*1.5mm |
| JS-H03 | 2000KG | 2300*1000*2550 | 2 |
Upright: 2550*1000*90*70*1.8mm Beam: 2300*120*45*1.5mm |
| JS-H04 | 3000KG | 2300*1000*2550 | 2 |
Upright: 2550*1000*90*70*2.0mm Beam: 2300*140*45*1.5mm |
| JS-H05 | 4000KG | 2300*1000*2550 | 2 |
Upright: 2550*1000*90*70*2.0mm Beam: 2300*160*45*1.5mm |
Selective pallet rack or heavy pallet rack is a common racking system in use today. Pallet rack systems consist of steel uprights and beams to support some type of decking to store goods. These systems offer maximum flexibility because the strength, height and length of the bays can be varied during installation to suit the stored material.
A1: Heavy-duty pallet racks maximize warehouse vertical space, provide 100% direct access to every pallet, accommodate a wide variety of goods, and easily integrate with standard forklifts and material handling equipment.
A2: Yes, size and load capacity are fully customizable. We accept bespoke size requests and load requirements up to 4000KG per layer or more based on your storage specifications.
A3: The rack design allows beams to be flexibly adjusted vertically. This makes it easy to modify the height space of each layer to adapt to changing cargo dimensions.
A4: The standard configuration is 2 layers (base level + 2 beam levels). However, extra layers can easily be added to your order depending on your ceiling height and load limits.
A5: Yes. The modular design of our heavy-duty pallet racks makes them easy to disassemble, reconfigure, and move to a new warehouse location if required.
