Cheapest and functional solution for all kinds of storage and low weight products. Designed with lots of different configurations, easy to set heights, distribution and weight levels. This storage system is usually used on the standard dimensions but it can also be adapted to the dimensions that the client requires.
| Model | Capacity (KG/Layer) | Size (L*W*H) mm | Material Thickness |
|---|---|---|---|
| JS-L1242 | 100KG | 1200*400*2000 | Column/Beam 0.6mm; Layer 0.3mm |
| JS-L1252 | 1200*500*2000 | ||
| JS-L1542 | 1500*400*2000 | ||
| JS-L1552 | 1500*500*2000 | ||
| JS-M1062 | 200KG | 1075*600*2000 | Column/Beam 0.7mm; Layer 0.3mm |
| JS-M1542 | 1500*400*2000 | ||
| JS-M1242 | 1200*400*2000 | ||
| JS-M1262 | 1200*600*2000 | ||
| JS-M1552 | 1500*500*2000 | ||
| JS-M2042 | 2000*400*2000 | ||
| JS-M1562 | 200KG | 1500*600*2000 | |
| JS-M2052 | 2000*500*2000 | ||
| JS-M2062 | 2000*600*2000 | ||
| JS-M1562L | 300KG | 1500*600*2000 | Column/Beam 0.9mm; Layer 0.4mm |
| JS-M2062L | 2000*600*2000 | ||
| JS-H2062 | 500KG | 2000*600*2000 | Column/Beam 1.1mm; Layer 0.5mm |
| Layers : | 4 | ||
| Color : | Blue / Orange / Grey-white | ||
| Other size and color can be customized based on the quantity of order. | |||
Depending on the specific model and material thickness configuration, our shelves can support weights ranging from 100KG to 500KG per layer. Please refer to the models table above to choose the exact specification that fits your warehouse load needs.
Yes. Standard colors include Blue, Orange, and Grey-white. Custom dimensions, layouts, and colors can be customized according to your requirement, depending on the quantity of your order.
The system features a highly functional design that makes assembly, disassembly, and adjustments extremely simple. Shelf heights can easily be configured or repositioned to fit different sizes of stored goods without professional tools.
The racking frames are manufactured using premium-grade steel. Depending on the loading weight category, column and beam thickness ranges from 0.6mm to 1.1mm, while the layer thickness ranges from 0.3mm to 0.5mm, ensuring high structural stability.
Absolutely. The modular system is designed to allow simple add-ons and expansions. You can easily extend your storage configuration by connecting additional shelving units as your warehouse capacity demands grow.
This system is ideal for manual loading of light to medium-weight products, including boxed inventory, large or bulky packages, and long metal or plastic components that require open, easy-access shelving storage.
