Factory Supply High Performance and Strong Long Span Storage Shelving Unit
Factory Supply High Performance and Strong Long Span Storage Shelving Unit
Factory Supply High Performance and Strong Long Span Storage Shelving Unit
Factory Supply High Performance and Strong Long Span Storage Shelving Unit
Factory Supply High Performance and Strong Long Span Storage Shelving Unit
1 / 5
Factory Supply High Performance and Strong Long Span Storage Shelving Unit
Factory Supply High Performance and Strong Long Span Storage Shelving Unit
Factory Supply High Performance and Strong Long Span Storage Shelving Unit
Factory Supply High Performance and Strong Long Span Storage Shelving Unit
Factory Supply High Performance and Strong Long Span Storage Shelving Unit

Factory Supply High Performance and Strong Long Span Storage Shelving Unit

Send Inquiry

Product Description

Racking System Layout
Racking System Dimensions
Model Capacity (KG/Layer) Size (L*W*H) mm Material Thickness
JS-L1242 100KG 1200*400*2000 Column/Beam 0.6mm;
Layer 0.3mm
JS-L1252 1200*500*2000
JS-L1542 1500*400*2000
JS-L1552 1500*500*2000
JS-M1062 200KG 1075*600*2000 Column/Beam 0.7mm;
Layer 0.3mm
JS-M1542 1500*400*2000
JS-M1242 1200*400*2000
JS-M1262 1200*600*2000
JS-M1552 1500*500*2000
JS-M2042 2000*400*2000
JS-M1562 1500*600*2000
JS-M2052 2000*500*2000
JS-M2062 2000*600*2000
JS-M1562L 300KG 1500*600*2000 Column/Beam 0.9mm;
Layer 0.4mm
JS-M2062L 2000*600*2000
JS-H2062 500KG 2000*600*2000 Column/Beam 1.1mm;
Layer 0.5mm
Layers : 4
Color : Blue / Orange / Grey-white
Other size and color can be customized based on the quantity of order.
Racking Structure Details
Shelving Component Info

Warehouse Racking System Light/Medium Duty Steel Storage Long Span Shelf

Cheapest and functional solution for all kinds of storage and low weight products. Designed with lots of different configurations, easy to set heights, distribution and weight levels. This storage system is usually used on the standard dimensions but it can also be adapted to the dimensions that the client requires.

BENEFITS OF LONG SPAN SHELVING:
  • 1. Easy assemble and disarmed.
  • 2. Easy to transport.
  • 3. Facilitates stock control.
  • 4. Cheap and functional.
  • 5. Easy Access.
  • 6. Lots of different applications.
APPLICATIONS:
  • 1. Low weight products.
  • 2. For materials that require more protection.
  • 3. Open shelving applications.
  • 4. Ideal for material resistant to deterioration.
  • 5. Lots of different combinations.
  • 6. Possibility to expand the system.
  • 7. Ideal to store boxes, big packages and long pieces.
Racking Application 1 Racking Application 2 Racking Application 3 Racking Application 4 Racking Application 5 Racking Application 6 Racking Application 7 Racking Application 8 Racking Application 9 Racking Application 10
Quality Standard Racking
Safe Storage Solutions
Racking Load Test
Warehouse Implementation
Frequently Asked Questions (FAQ)
Q1: What weight capacities do these long span shelving units support?
A1: Our racking systems are available in light to medium duty capacities, ranging from 100KG, 200KG, 300KG, up to 500KG per layer, depending on the model and material thickness chosen.
Q2: Can I get customized sizes and colors?
A2: Yes, while the standard colors are Blue, Orange, and Grey-white, other sizes and colors can be fully customized based on the quantity of your order.
Q3: How many layers come standard with these shelving units?
A3: The standard configuration features 4 layers, but it can be designed with many different configurations to adapt to the specific dimensions you require.
Q4: Are these warehouse racks easy to install and move?
A4: Absolutely. One of the main benefits of our long span shelving is that it is easy to assemble, disassemble, and transport, making it a highly flexible storage solution.
Q5: What are the typical applications for light and medium duty shelves?
A5: They are ideal for storing low-weight products, boxes, big packages, long pieces, and materials requiring protection. It is a highly cost-effective and functional solution for general open shelving needs.
Q6: What is the material thickness of the columns and layers?
A6: The thickness scales with load capacity. For example, our 100KG light-duty model has a column/beam thickness of 0.6mm and layer thickness of 0.3mm, while the 500KG model uses a 1.1mm column/beam and a 0.5mm layer.
